UPVC Elbow 45 Degree

WRAS certified epco UPVC Elbow 45 Degree are made of unplasticized polyvinyl chloride. Metric 45 Degree Elbow pressure pipe fittings are available in sizes ranging from 10mm o.d. to 50mm o.d. up to 400mm outside diameter.

Plastic 45 Degree Elbows are pipe fittings used to produce a 45-degree angle by connecting two sections of pipe of the same diameter.

To perform this correctly, read the assembly and joining method recommendations in our technical information and make sure you have the proper UPVC Elbow 45 Degree solvent cement and cleaner for bonding pipe and fittings together. These can be found in our section on metric accessories.

Our UPVC pressure pipe range is made of unplasticized polyvinyl chloride and has a working temperature of +5°C to +60°C depending on the system pressure. Also available UPVC Elbow 45 Degree and 90 Degree Elbow pipe fittings.

UPVC Elbow 45 Degree Details

ID – Inner Diameter,
OD – Outer Diameter,
WT – Wall Thickness,
SL – Socket Length,
L – Leg Length,
H – Height

Size (Inch)	ID (mm)	OD (mm)	WT (mm)	SL (mm)	L (mm)	H (mm)
½	21.64	29.10	3.73	22.23	45	59
¾	26.97	34.79	3.91	25.40	58	68
1	33.78	42.88	4.55	28.58	60	74
1¼	42.55	52.25	4.85	31.75	77	85
1½	48.72	58.88	5.08	34.93	83	88
2	60.78	71.86	5.54	38.10	98	115
2½	73.56	87.58	7.01	44.45	130	168
3	89.50	104.74	7.62	47.63	126	188
4	114.99	132.11	8.56	57.15	145	235

Symbol	Parameter Name	Description
DN / NB	Nominal Size	Nominal pipe size
OD	Outside Diameter	Outside diameter of pipe/socket
R	Centerline Radius	Radius of elbow (45° bend)
L	Center-to-End	Distance from socket end to center
S	Socket Depth	Pipe insertion depth
T	Wall Thickness	Elbow body wall thickness
θ	Bend Angle	45°

Feature	Details
Angle of Turn	45 degrees
Flow Efficiency	Higher – allows smoother transitions
Pressure Loss	Lower – reduces resistance
Turbulence	Less turbulence compared to 90-degree elbows
Wear on Pipes	Less wear due to gradual turn
Common Uses	HVAC, chemical, industrial piping
Space Requirements	Takes up more space due to the gradual bend
Installation Complexity	Easier in open spaces but needs planning for alignment

A) ASTM System (Solvent Weld)

Class	Working Pressure @ 23 °C	Pressure (bar)	Pressure (psi)
Schedule 40	Medium pressure	10–16 bar	150–300 psi
Schedule 80	High pressure	16–25 bar	230–400 psi

B) ISO / DIN PN System

PN Class	Max Working Pressure	Application
PN 6	6 bar	Drainage / low pressure
PN 10	10 bar	Chemical supply
PN 16	16 bar	Industrial piping
PN 20	20 bar	High-pressure service
PN 25	25 bar	Heavy-duty applications

2. Pressure Rating Reduction with Temperature

Temperature (°C)	Allowable Pressure Factor
23	1.00
30	0.88
40	0.75
50	0.62
60	0.50

3. Pressure Rating by Elbow Type

Elbow Type	Pressure Rating
Socket (Solvent Weld) 45°	Same as pipe rating
Threaded 45° Elbow	~20–25% lower
Rubber Ring (Push-Fit)	PN 6 – PN 10
Fabricated 45° Elbow	As per design & welding

Property	Typical Value	Remarks
Material	uPVC (Unplasticized Polyvinyl Chloride)	Rigid thermoplastic
Color	Grey / White	UV-stabilized grades available
Density	1.38–1.45 g/cm³	Lightweight
Surface Finish	Smooth, glossy	Low friction
Weight	Light	Easy handling & installation
Hardness (Shore D)	75–85	Rigid material
Water Absorption	≤ 0.1%	Non-hygroscopic
Thermal Conductivity	0.14–0.16 W/m·K	Good thermal insulation
Electrical Conductivity	Non-conductive	Excellent insulator
Coefficient of Friction	~0.2	Smooth internal bore
Transparency	Opaque	Prevents algae growth
Odor / Taste	Odorless, non-toxic	Suitable for potable chemical

45° Elbow Connection & Configuration

Connection Type	End Configuration	Standard Used	Sealing Method	Typical Application
Socket × Socket	Female sockets on both ends	ASTM D2466 / ISO 1452	Solvent cement	Pressure piping
Socket × Threaded	One socket, one male/female thread	ASTM D2464 / BSP / NPT	Solvent cement + PTFE tape	Equipment connection
Threaded × Threaded	Male or female threads both ends	BSP / NPT	PTFE tape/thread sealant	Removable joints
Rubber Ring (RR)	Push-fit socket ends	EN 1401	Elastomeric gasket	Drainage & sewer
Spigot × Socket	Plain end + socket	ISO / DIN	Rubber ring or solvent	Underground piping

Types of UPVC 45 degree Elbow

Type	End Connection	Description	Standard / System	Typical Application
Socket (Solvent Weld) 45° Elbow	Socket × Socket	Smooth female sockets on both ends	ASTM D2466 / ISO 1452	Pressure water lines
Threaded 45° Elbow	Male × Male / Female × Female	Screwed threaded ends	BSP / NPT	Equipment & service connections
Socket × Threaded 45° Elbow	Socket × Male/Female	One solvent weld end, one threaded end	ASTM / BSP / NPT	Transition joints
Molded 45° Elbow	Socket × Socket	One-piece molded fitting	ASTM / ISO	Pressure systems
Fabricated 45° Elbow	Welded segments	Made from pipe sections	Project-specific	Large diameters
Long Radius 45° Elbow	Socket × Socket	Larger centerline radius	ASTM / ISO	High-flow, low-loss lines
Short Radius 45° Elbow	Socket × Socket	Compact bend radius	ASTM / ISO	Space-limited areas
Rubber Ring (Push-Fit) 45° Elbow	RR Socket × Socket	Elastomeric gasket sealing	EN 1401 / ISO 3633	Drainage & sewer
Spigot End 45° Elbow	Spigot × Socket	Plain end for RR joint	ISO / DIN	Underground piping

Benefits of Using UPVC Elbow 45 Degree

Versatility

One of the main advantages of using a upvc 45 degree elbow in construction and infrastructure projects is its versatility. It can be used in many applications and with different materials. This means that the upvc 45 degree elbow can accommodate numerous pipe sizes and types, making it an ideal solution for many chemical applications.

Easy installation

Installing a upvc 45 degree elbow is relatively straightforward and requires minimal effort. The fitting can be easily integrated into existing systems, saving time and labour costs. In addition, its design provides a tight and secure connection, reducing the risk of leaks and Chemical damage.

Improved aesthetics

A upvc 45 degree elbow also offers an aesthetic advantage for building and infrastructure projects. It has a sleek design that can complement the overall layout of the building or infrastructure. The fitting is available in a range of materials including brass, chrome and stainless steel, offering a variety of options.

Cost effective

Choosing a upvc 45 degree elbow for construction and infrastructure projects is cost effective. The fitting is economical and offers long-lasting performance, eliminating the need for frequent repairs or replacements. By saving on costs, contractors and building owners can allocate resources to other areas of the project.

Why Choose Petron Thermoplast?

At Petron Thermoplast, we are committed to providing top-notch upvc 45 degree elbows and other products designed to meet the highest industry standards. Here’s why you should choose us:

Durability

Our products are built to last, offering excellent resistance to corrosion and wear. We use high-quality materials and advanced manufacturing processes to ensure our fittings can withstand harsh conditions and provide reliable performance over time.

Quality Assurance

We follow strict quality control measures to ensure our fittings meet all required specifications. Our products undergo extensive testing to ensure they meet or exceed industry standards for strength, durability, and performance.

Expert Support

Our team of experts is always ready to help you choose the right products for your needs. We provide technical support and guidance to help you select the best for your specific applications, ensuring optimal performance and efficiency.

UPVC Pipe Fittings

We offer UPVC Pipe Fittings products in all standard sizes and provide complete customization options to meet your specific project requirements across our entire product range.
