UPVC Hose Adaptor Spigot End
The UPVC Hose Adaptor with Spigot End is a specialized fitting designed to connect flexible hoses to rigid UPVC piping systems. The spigot end fits into standard UPVC sockets or fittings, while the barbed end ensures a secure grip for flexible hoses. Constructed from high-quality Unplasticized Polyvinyl Chloride (UPVC), this adaptor is ideal for applications in irrigation, fluid transfer, and water treatment systems.
- Chemical Resistance
- Low Maintenance Requirement
- Low Thermal Conductivity
- Long Service Life
- Easy Installation
- Corrosion Resistance
UPVC Hose Adaptor Spigot End Details
Nominal Size (Inch) → Nominal Pipe Size (in inches)
O.D. → Outer Diameter
D → Spigot Outer Diameter
N → Barb Length
L → Overall Length
Z → Barb Outer Diameter
| Nominal Size (Inch) | Spigot O.D. (D) | Barb Length (N) | Overall Length (L) | Barb O.D. (Z) |
| 1/2″ | 0.840″ | 1.25″ | 2.50″ | 0.53″ |
| 3/4″ | 1.050″ | 1.50″ | 2.85″ | 0.78″ |
| 1″ | 1.315″ | 1.75″ | 3.25″ | 1.03″ |
| 1-1/2″ | 1.900″ | 2.00″ | 3.75″ | 1.53″ |
| 2″ | 2.375″ | 2.25″ | 4.25″ | 2.03″ |
| 3″ | 3.500″ | 3.00″ | 5.50″ | 3.05″ |
| 4″ | 4.500″ | 3.50″ | 6.50″ | 4.05″ |
| Parameter | Details |
| Product Name | UPVC Hose Adaptor (Spigot End) |
| Material | Unplasticized Polyvinyl Chloride (UPVC) |
| Function | Connects flexible hose to UPVC piping system |
| Type | Spigot × Hose Tail (Barbed) Adaptor |
| End Connection | Spigot (plain end) × Hose barb end |
| Jointing Method | Solvent weld (spigot end) + Hose clamp (hose end) |
| Shape | Cylindrical with barbed/ribbed hose end |
| Size Range | 15 mm to 110 mm (½″ to 4″ approx.) |
| Pressure Rating | PN6 / PN10 (depends on size and application) |
| Temperature Range | 0°C to 60°C |
| Standards | ASTM D2467, DIN, ISO |
| Color | Grey / White |
| Density | ~1.38 – 1.45 g/cm³ |
| Surface Finish | Smooth internal bore, ribbed hose end |
| Mechanical Strength | Good tensile and impact strength |
| Chemical Resistance | Excellent resistance to acids, alkalis, and salts |
| Corrosion Resistance | 100% corrosion-free, rust-proof |
| Thermal Conductivity | Low (good insulation properties) |
| Electrical Properties | Non-conductive |
| Water Absorption | Very low (<0.5%) |
| Hose Grip | Strong grip due to barbed design |
| Leak Tightness | Leak-proof when properly solvent welded and clamped |
| Weight | Lightweight, easy handling |
| Durability | Long service life (25–50 years) |
| Maintenance | Low maintenance |
| Applications | Irrigation, gardening, water supply, industrial hose connections |
Dual-End Design: Spigot end for solvent welding to pipes; barbed end for hose connection.
Secure Hose Grip: Barbed design prevents hose slippage and ensures leak-free operation.
Corrosion & Chemical Resistant: Suitable for use with a wide range of fluids and environments.
Durable & Lightweight: Offers high impact strength with ease of handling.
Easy Installation: Quick and reliable connection without the need for special tools.
Versatile Application: Compatible with both soft hoses and rigid piping.
| Parameter | Details |
| Standard Pressure Rating | Up to 6 bar (≈90 psi) |
| Maximum Pressure Range | 6 – 16 bar (PN6–PN16) |
| PN Classification | PN6 / PN10 / PN16 |
| Pressure Rating (PN6) | 6 bar |
| Pressure Rating (PN10) | 10 bar |
| Pressure Rating (PN16) | 16 bar |
| Working Temperature for Rating | ~20–23°C (Ambient conditions) |
| Temperature Effect | Pressure rating decreases as temperature increases |
| Limiting Factor | Hose connection (clamp & hose strength) limits actual pressure |
| Recommended Application Pressure | Low to medium pressure systems |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Benefits of Using UPVC Hose Adaptor Spigot End
Secure Pipe-to-Hose Connection
- Provides a reliable transition from rigid UPVC pipe to flexible hose
- Barbed hose tail ensures a strong grip when used with a clamp
Easy & Quick Installation
- Spigot end solvent-welds easily into UPVC socket fittings
- Hose side connects without threading or special tools
- Reduces installation time and labour cost
Lightweight & Easy Handling
- Much lighter than metal adaptors
- Easy to carry, align, and install, even in confined spaces
Corrosion & Chemical Resistance
- UPVC is rust-free and corrosion-proof
- Suitable for water, irrigation, and many mild chemical applications
Cost-Effective Solution
- Lower cost compared to metal hose adaptors
- No need for painting, coating, or corrosion protection
- Minimal maintenance over service life
Leak-Free Performance
- Solvent-welded spigot end creates a permanent, leak-tight joint
- Hose tail with clamp ensures secure sealing on the hose side
Smooth Internal Bore
- Minimises pressure loss and turbulence
- Improves flow efficiency compared to rough metal fittings
Flexible System Design
- Allows use of flexible hoses for vibration absorption and alignment
- Ideal for pump connections and portable equipment
Wide Size Availability
- Available in multiple pipe and hose sizes
- Reducer versions available for mismatched connections
Low Maintenance & Long Service Life
- Resistant to scaling, fouling, and environmental degradation
- Long-lasting in outdoor and wet environments
Types of UPVC Hose Adaptor Spigot End
1️. Straight Hose Adaptor (Spigot × Hose Tail)
- One end: UPVC spigot (solvent-weld)
- Other end: hose tail / barbed end
- Designed to connect a UPVC pipe to a flexible hose using a clamp
2️. Male Threaded Hose Adaptor (Spigot × Male Thread × Hose Tail)
- Spigot is d solvent-weldedto theo pipe
- Male threaded portion for valve/tap
- Hose tail for flexible hose
3️. Reducer Hose Adaptor (Spigot × Hose Tail – Reducing)
- Different pipe and hose sizes
- Spigot size ≠ hose tail size
- Allows connection between mismatched sizes
4️. Heavy-Duty Hose Adaptor (Thick-Wall Type)
- High-strength design
- Reinforced hose tail
- Thicker spigot wall
5️. Long-Tail Hose Adaptor
- Extended hose barb length
- Longer gripping surface for the hose
- Improved pull-out resistance
6️. Brass-Insert Hose Adaptor (Spigot End)
- Hybrid construction
- UPVC spigot with brass insert at threaded or hose side
- Improves durability and thread life
7️. Hose Adaptor with Clamp Groove
- Enhanced hose retention
- Hose tail designed for clamp seating
- Prevents hose slippage
