Testing and quality control are the critical aspects of acid storage tank to manufacturing. Since these tanks are designed to store the highly corrosive chemicals, they must be undergo rigorous inspections and testing to ensure the structural integrity, leak-tight performance, chemical resistance, and long-term operational safety. A comprehensive quality to assurance the program to helps the prevent failures, environmental contamination, and costly downtime.

Importance of Quality Testing

Quality testing ensures that the acid storage tank:

• Meets design specifications
• Safely withstands chemical exposure
• Maintains structural stability
• Prevents leaks and spills
• Complies with industry standards
• Delivers long service life

1. Raw Material Inspection

Quality control begins with the inspection of incoming raw materials.

Inspection Parameters:

• Material grade verification
• Material Test Certificate (MTC) review
• Sheet thickness measurement
• Surface condition inspection
• Dimensional verification
• Traceability confirmation

Only approved materials are used for tank fabrication.

2. In-Process Fabrication Inspection

During manufacturing, inspections are carried out at various stages.

Checks Include:

• Sheet cutting accuracy
• Component dimensions
• Shell alignment
• Bottom and roof fit-up
• Nozzle positioning
• Reinforcement placement

Continuous monitoring helps maintain fabrication quality.

3. Visual Inspection

Visual inspection is performed throughout fabrication and after completion.

Inspection Covers:

• Surface defects
• Scratches and dents
• Material damage
• Weld appearance
• Accessory installation quality
• Overall workmanship

This is the first step in identifying potential defects.

4. Welding Quality Inspection

Welds are critical to the performance of thermoplastic acid storage tanks.

Weld Inspection Parameters:

• Uniform weld bead formation
• Proper fusion
• Weld continuity
• Surface finish
• Absence of cracks
• Absence of porosity and voids

Qualified inspectors verify compliance with approved welding procedures.

5. Dimensional Inspection

Dimensional checks ensure that the finished tank conforms to approved drawings.

Parameters Measured:

• Tank diameter
• Tank height
• Wall thickness
• Roof dimensions
• Nozzle locations
• Manhole positioning
• Verticality and roundness

Accurate dimensions ensure proper installation and operation.

6. Hydrostatic Testing

Hydrostatic testing is one of the most important quality tests performed on acid storage tanks.

Purpose:

• Verify leak-tightness
• Evaluate structural integrity
• Confirm weld performance

Test Procedure:

1. The tank is filled with clean water.
2. The water level is gradually increased.
3. The tank is held under test conditions for a specified period.
4. Welds, joints, and fittings are inspected for leaks or deformation.

Successful completion confirms the tank’s ability to withstand service conditions.

7. Spark Testing (Holiday Testing)

Spark testing is commonly used for lined or dual-laminate tanks.

Purpose:

• Detect pinholes
• Identify liner defects
• Verify liner continuity

This test helps ensure complete protection against chemical attack.

8. Vacuum Testing

Vacuum testing may be performed on tanks designed for vacuum service.

Evaluation Includes:

• Vacuum retention capability
• Structural stability
• Joint integrity

The tank must withstand specified vacuum conditions without deformation.

9. Leak Testing of Nozzles and Connections

All process connections are checked for leak-tight performance.

Components Tested:

• Inlet nozzles
• Outlet nozzles
• Drain connections
• Vent connections
• Instrument ports

Leak-free connections are essential for safe acid storage.

10. FRP Reinforcement Inspection (For Dual-Laminate Tanks)

For FRP-backed thermoplastic tanks, the FRP layer is inspected.

Inspection Parameters:

• Laminate thickness
• Resin curing quality
• Air void detection
• Structural reinforcement placement
• Surface finish

Proper reinforcement enhances mechanical strength and durability.
