HDPE Flexible Tubing
HDPE flexible tubing (6720) is made from high-density polyethene.You can get HDPE flexible tubing from Petron Thermoplast Direct by clicking the link above.
Applications
The brewing and culinary industries use low-pressure pneumatic applications.
Key Features of HDPE Flexible Tubing
Temperature: -20°C to +50°C.
Density: 0.958g/cm3.
Excellent water and organic salt solution resistance.
Chemical resistance is excellent.
HDPE is also allowed for use in Food.
Metric HDPE Flexible Tubing
| Product Code | Inside Diameter (mm) | Outside Diameter (mm) | Wall Thickness (mm) | Working Pressure (Bar) | Colour | Coil Length (mtr) |
|---|---|---|---|---|---|---|
| 6720N-4X6 | 4.0 | 6.0 | 1.0 | 36 | Natural | 30 / 100 |
| 6720N-6X8 | 6.0 | 8.0 | 1.0 | 24 | Natural | 100 |
| 6720N-8X10 | 8.0 | 10.0 | 1.0 | 18 | Natural | 100 |
| 6720N-9X12 | 9.0 | 12.0 | 1.50 | 24 | Natural | 100 |
Note: Other colours and diameters may be available (subject to minimum order quantity), please enquire.
Imperial HDPE Flexible Tubing
| Product Code | Inside Diameter (mm) | Outside Diameter (mm) | Working Pressure (Bar) | Colour | Coil Length (mtr) |
|---|---|---|---|---|---|
| 6720N-6.35×9.52 | .250 – 6.35 | 3/8 – 9.52 | 36 | Natural | 100 |
| 6720N-9.53×12.70 | .375 – 9.53 | ½ – 12.70 | 24 | Natural | 100 |
Note: Other colours and diameters may be available (subject to minimum order quantity), please enquire.
