UPVC Pipes
UPVC (Unplasticized Polyvinyl Chloride) Pipes are strong, rigid pipes used for transporting fluids in residential, commercial, and industrial settings. Manufactured without plasticizers, they offer higher strength and chemical resistance than regular PVC. UPVC pipes suit cold water, drainage, irrigation, and industrial fluids because of their non-reactive, corrosion-resistant properties.
Our UPVC Pipe system does not get affected by strong chemicals present in nature, like mineral acids, alkalis, and salts, as well as a large number of organic solvents. It also provides immunity against toxic UV radiation and harmful bacteria, which makes them perfect for liquid transportation even under harsh circumstances. You’ll be surprised after knowing the different UPVC pipe sizes that we have in store for you, and if you’re worried about the installation, then worry no more because our UPVC pipes and fittings are extremely light in weight and easy to handle. In addition to this, they can easily be installed in minutes with smooth jointing using a special solvent cement supplied by the company, which reduces labour and installation costs.
Our UPVC pipe fittings are lead-free, resistant to corrosion, and prevent negative biological effects. Their non-toxic nature ensures a healthy potable water flow and meets ASTM standards.
- Chemical Resistance
- Low Maintenance Requirement
- Low Thermal Conductivity
- Long Service Life
- Easy Installation
- Corrosion Resistance
UPVC Pipes Details
- OD – Outer Diameter
| Nominal Size | Average OD (mm) | Minimum Wall Thickness (mm) |
| ½″ (15 mm) | 21.34 | 3.73 |
| ¾″ (20 mm) | 26.67 | 3.91 |
| 1″ (25 mm) | 33.40 | 4.55 |
| 1¼″ (32 mm) | 42.16 | 4.85 |
| 1½″ (40 mm) | 48.26 | 5.08 |
| 2″ (50 mm) | 60.32 | 5.54 |
| 2½″ (65 mm) | 73.02 | 7.01 |
| 3″ (80 mm) | 88.90 | 7.62 |
| 4″ (100 mm) | 114.30 | 8.56 |
| 5″ (125 mm) | 141.30 | 9.62 |
| 6″ (150 mm) | 168.28 | 10.97 |
| 8″ (200 mm) | 219.08 | 12.70 |
| 10″ (250 mm) | 273.05 | 15.06 |
| 12″ (300 mm) | 323.85 | 17.45 |
| Parameter | Specification |
| Material | UPVC (Unplasticized Polyvinyl Chloride) |
| Size Range | ½” to 12” (15 mm to 315 mm) |
| Standard Length | 3 m / 6 m |
| Wall Thickness | SCH 40 / SCH 80 / As per ASTM / DIN standards |
| Operating Pressure | Up to 15 bar (depending on size and class) |
| Temperature Range | 0°C to 60°C (32°F to 140°F) |
| Color | Generally Grey or White |
| Joining Methods | Solvent Cement, Threaded, Flanged |
| Standards Compliance | ASTM D1785, ASTM D2467, ISO, DIN |
Corrosion and Chemical Resistant: Ideal for transporting a wide range of chemicals and aggressive media.
Smooth Inner Surface: Reduces friction loss and prevents scaling or sediment build-up.
Lightweight and Easy to Handle: Simplifies transportation and installation.
Low Thermal Conductivity: Minimizes heat loss in fluid transport systems.
Non-Toxic and Lead-Free: Safe for potable water applications.
Long Service Life: High durability and low maintenance requirements.
UV Resistant (with additives): Suitable for above-ground installations.
Metric Pressure Ratings (PN Class)
| PN Class | Pressure Rating @ 27°C | Equivalent (psi) |
| PN 4 | 4 bar | 58 psi |
| PN 6 | 6 bar | 87 psi |
| PN 8 | 8 bar | 116 psi |
| PN 10 | 10 bar | 145 psi |
| PN 12.5 | 12.5 bar | 181 psi |
| PN 16 | 16 bar | 232 psi |
American Standard Pressure Ratings (ASTM)
| Pipe Schedule | Pressure Rating (Approx.) | Equivalent (psi) |
| Schedule 40 | 10–14 bar | 150–200 psi |
| Schedule 80 | 20–24 bar | 300–350 psi |
| PN Class | Max Working Pressure | Equivalent (psi) |
| PN 4 | 4 bar | 58 psi |
| PN 6 | 6 bar | 87 psi |
| PN 8 | 8 bar | 116 psi |
| PN 10 | 10 bar | 145 psi |
| PN 12.5 | 12.5 bar | 181 psi |
| PN 16 | 16 bar | 232 psi |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Benefits of Using UPVC Pipes
Corrosion-free
No rust, scaling, or electrochemical reaction
Long service life
Typically 50+ years under normal conditions
Lightweight
Easy to handle, transport, and install
High pressure resistance
Available in PN 6 to PN 16 and higher
Smooth inner surface
Low friction loss, better flow efficiency
Leak-proof joints
Solvent cement joints ensure tight sealing
Excellent chemical resistance
Suitable for acids, alkalis, and salts
Low maintenance
Minimal repairs and operating cost
Cost-effective
Cheaper than metal piping systems
Non-toxic
Safe for potable drinking water
Low thermal conductivity
Reduces heat loss and condensation
Good impact strength
Durable under normal handling
Self-extinguishing
Does not support combustion
Easy customization
Simple cutting, joining, and modification
Resistant to biological growth
No algae or bacterial buildup
Environment-friendly
Recyclable material
Types of UPVC Pipes
UPVC Pressure Pipes
Used for water supply, irrigation, industrial pipelines
UPVC Chemical Pipes
Internal and external chemical systems
UPVC Drainage Pipes
Wastewater and rainwater drainage
UPVC Sewer Pipes
Underground sewage and soil lines
UPVC Casing Pipes
Bore well and tube well applications
UPVC Conduit Pipes
Electrical cable protection
UPVC Column Pipes
Submersible pump installations
Why Choose Petron Thermoplast?
At Petron Thermoplast, we offer a wide range of high-quality water supply pipes and chemical solutions. Our products are designed to meet international standards, ensuring durability, reliability, and superior performance. From PVC, CPVC, UPVC, Agriline, Column, to Casing pipes, we have the perfect solution for your needs.
Benefits of Choosing Petron Thermoplastic pipes Certified and durable chemical pipes, Wide range of sizes and materials,Expert guidance for selecting the right pipe, Competitive pricing and fast delivery
UPVC Pipe Fittings
We offer UPVC Pipe Fittings products in all standard sizes and provide complete customization options to meet your specific project requirements across our entire product range.
