CPVC Basket Strainer
The CPVC Basket Strainer is a high-performance filtration component designed to remove debris and solid particles from fluid systems, protecting downstream equipment like pumps, valves, and meters. Constructed from chemically resistant Chlorinated Polyvinyl Chloride (CPVC), it is ideal for applications involving corrosive fluids and elevated temperatures. The basket-style strainer offers a larger filtration area compared to Y-strainers, making it suitable for high-flow and continuous-duty systems in industrial and chemical processing environments.
Key Features of CPVC Basket Strainer
Large Filtration Capacity: Basket design allows greater debris collection and longer service intervals.
Durable CPVC Construction: Excellent resistance to corrosion and harsh chemicals.
High Temperature Tolerance: Suitable for applications up to 93°C (200°F).
Removable Basket: Easy maintenance and cleaning without removing the strainer body from the line.
Low Pressure Drop: Efficient flow design reduces energy consumption.
Secure Flanged or Threaded Ends: Ensures leak-proof installation and system integrity.
Optional Drain Port: Enables easy flushing and cleaning without dismantling.
Visual Access (optional): Clear cover options available for visual inspection of basket condition.
Technical Information
| Parameter | Details |
|---|---|
|
Body Material |
CPVC (Chlorinated Polyvinyl Chloride) |
|
Basket Material |
Stainless Steel, CPVC, or PVDF-coated options |
|
Seal Material |
EPDM or FKM (Viton®) |
|
Size Range |
1″ to 6″ (25 mm to 150 mm) |
|
End Connections |
Flanged, Threaded (NPT/BSP), or Socket (solvent weld) |
|
Operating Pressure |
Up to 150 PSI (10.3 bar) at 23°C |
|
Temperature Range |
0°C to 93°C (32°F to 200°F) |
|
Screen/Basket Options |
20–100 mesh (depending on application) |
|
Installation Orientation |
Horizontal preferred |
|
Drain Port |
Available (depending on model) |
|
Compliance Standards |
ASTM D1784 (CPVC material), NSF/ANSI 61 (if applicable) |
|
Applications |
Chemical processing, industrial piping, RO plants, water treatment |
