CPVC Electric Actuator Butterfly Valve
A CPVC Electric Actuator Butterfly Valve is an automated flow control valve made from Chlorinated Polyvinyl Chloride (CPVC) material and operated by an electric actuator. It is designed to regulate, start, or stop the flow of liquids in a piping system using a rotating disc mechanism controlled electrically. The CPVC Electric Actuator Butterfly Valve consists of a circular disc mounted on a shaft inside the valve body. When the electric actuator receives a signal, it rotates the disc 90 degrees to either allow full flow, restrict flow, or completely shut off the pipeline.
A CPVC Electric Actuator Butterfly Valve is used for fast control and ON/OFF operations. There GR-PP, and resistant to UV rays, and interchangeable discs with a full flanged body with oval holes to fit with flanges in different standards; equipped with CPVC inserts to centre flanges and bolts, drilling on request according to different standards. It is possible to mounting of valve as an end valve, or quick discharge from tanks.
- Chemical Resistance
- Low Maintenance Requirement
- Low Thermal Conductivity
- Long Service Life
- Easy Installation
- Corrosion Resistance
CPVC Electric Actuator Butterfly Valve Details
D / DN: Outer diameter and Nominal diameter of the pipe connection.
PN: Nominal Pressure rating (maximum allowable pressure at 23°C).
B2 / B7: Specific body and assembly width measurements.
H: Overall height of the valve assembly.
T1: Thickness or depth of the flange/mounting section.
f: Bolt hole diameter or spacing parameter.
| D (mm) | DN (mm) | PN (Bar) | B2 (mm) | B7 (mm) | H (mm) | T1 (mm) | f (mm) |
| 50 | 40 | 16 | 60 | 253 | 132 | 92 | 18 |
| 63 | 50 | 16 | 70 | 259 | 147 | 92 | 18 |
| 75 | 65 | 10 | 80 | 266 | 165 | 92 | 18 |
| 90 | 80 | 10 | 93 | 308 | 185 | 128 | 22 |
| 110 | 100 | 10 | 107 | 322 | 211 | 128 | 22 |
| 125 | 140 | 10 | 120 | 425 | 240 | 170 | 22 |
| 160 | 150 | 10 | 134 | 438 | 268 | 170 | 22 |
| 225 | 200 | 10 | 161 | 485 | 323 | 170 | 22 |
| 280 | 250 | 10 | 210 | 597 | 405 | 170 | 26 |
| 315 | 300 | 8 | 245 | 654 | 475 | 170 | 26 |
| Parameter / Property | Details / Value |
| Valve Type | Butterfly Valve (Quarter-turn) |
| Actuation | Electric (Motorized Actuator) |
| Body Material | CPVC (Chlorinated Polyvinyl Chloride) |
| Disc Material | CPVC / PP / PVDF |
| Seat Material | EPDM / FKM (Viton) |
| Size Range | 2” to 12” (DN50 to DN300) |
| Pressure Rating | PN6 / PN10 |
| Temperature Range | 0°C to 90°C |
| Connection / Standard | Wafer / Lug Type (ANSI / DIN / JIS) |
| Voltage Supply | 24V DC / 110V AC / 230V AC / 415V AC |
| Control Type | On/Off or Modulating (4–20 mA / 0–10V) |
| Operation Time | 5–30 seconds |
| Mounting / Protection | ISO 5211 / IP65 or IP67 |
| Features | Manual Override & Built-in Limit Switches |
| Density | 1.45 – 1.58 g/cm³ |
| Tensile / Flexural Strength | 50 – 70 MPa / 80 – 100 MPa |
| Thermal Conductivity | ~0.14 W/m·K |
| Coeff. of Thermal Expansion | 6–7 × 10⁻⁵ /°C |
| Chemical Resistance | Excellent (Acids, Alkalis, Salts) |
| Flammability | Self-extinguishing |
| Electrical Conductivity | Non-conductive |
| UV Resistance | Moderate (Outdoor protection recommended) |
- Corrosion-Resistant CPVC Body
Made from high-quality CPVC material, offering excellent resistance to acids, alkalis, and corrosive chemicals. - Electric Actuated Operation
Motorised actuator enables automatic opening and closing without manual effort. - Quarter-Turn (90°) Operation
Fast and efficient flow control with simple 0° to 90° disc rotation. - On/Off and Modulating Control Options
Available for both fully open/closed applications and precise flow regulation (4–20 mA / 0–10V). - Leak-Proof Sealing System
Equipped with an EPDM or FKM seat for tight shut-off and minimal leakage. - Compact and Lightweight Design
Easier installation and handling compared to metal valves. - Wide Size Range
Available in multiple sizes for small to large pipeline systems. - High Temperature Resistance
Suitable for fluid temperatures up to approximately 90°C. - Low Maintenance Requirement
Non-metallic construction prevents rust, scaling, and frequent servicing. - IP Rated Actuator (IP65 / IP67)
Dustproof and water-resistant actuator suitable for industrial and outdoor environments. - Manual Override Option
Allows manual operation in case of power failure. - Energy Efficient Operation
Consumes power only during the opening or closing movement.
| Nominal Size (Inch) | Nominal Size (mm) | Pressure Class | Max Working Pressure (Bar) | Max Working Pressure (kg/cm²) |
| 1½” | 40 mm | PN10 | 10 Bar | 10 kg/cm² |
| 2” | 50 mm | PN10 | 10 Bar | 10 kg/cm² |
| 2½” | 65 mm | PN10 | 10 Bar | 10 kg/cm² |
| 3” | 80 mm | PN10 | 10 Bar | 10 kg/cm² |
| 4” | 100 mm | PN10 | 10 Bar | 10 kg/cm² |
| 5” | 125 mm | PN6 – PN10 | 6 – 10 Bar | 6 – 10 kg/cm² |
| 6” | 150 mm | PN6 | 6 Bar | 6 kg/cm² |
| 8” | 200 mm | PN6 | 6 Bar | 6 kg/cm² |
| 10” | 250 mm | PN6 | 6 Bar | 6 kg/cm² |
| 12” | 300 mm | PN6 | 6 Bar | 6 kg/cm² |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Benefits of Using CPVC Electric Actuator Butterfly Valve
Fully Automated Operation
An electric actuator enables remote and automatic control, reducing manual intervention.
Excellent Corrosion Resistance
CPVC construction provides superior resistance to acids, alkalis, salts, and aggressive chemicals.
Accurate Flow Control
Suitable for both On/Off and modulating control (4–20 mA / 0–10V), allowing precise regulation.
Low Maintenance
Non-metallic body prevents rusting and scaling, increasing service life.
Energy Efficient
Electric actuators consume power only during operation (open/close movement).
Compact & Lightweight Design
Easier installation compared to metal butterfly valves with pneumatic systems.
Leak-Proof Sealing
EPDM or FKM seat ensures a tight shut-off and minimal leakage.
Fast Quarter-Turn Operation
90° rotation allows quick opening and closing.
High Temperature Capability
Suitable for applications up to approximately 90°C.
Cost-Effective Automation Solution
Lower installation and operating costs compared to hydraulic or pneumatic actuators.
Safe & Spark-Free Operation
Ideal for chemical plants and oil, gas treatment systems.
Versatile Applications
Widely used in water treatment plants, chemical processing industries, irrigation systems, and industrial fluid handling.
Types of CPVC Electric Actuator Butterfly Valve
On/Off Type CPVC Electric Actuator Butterfly Valve
- Operates in a fully open or fully closed position
- Suitable for simple start/stop flow control
- Commonly used in water and chemical transfer systems
Modulating Type CPVC Electric Actuator Butterfly Valve
- Allows partial opening (0–90° control)
- Controlled by a 4–20 mA or 0–10V signal
- Ideal for precise flow regulation
Wafer Type CPVC Electric Actuator Butterfly Valve
- Compact design installed between two flanges
- Lightweight and cost-effective
- Suitable for standard pipeline systems
Lug Type CPVC Electric Actuator Butterfly Valve
- Threaded inserts (lugs) on the body
- Allows easy installation and maintenance
- Suitable for end-of-line service
Flanged Type CPVC Electric Actuator Butterfly Valve
- Designed with full flanged ends
- Used in large diameter and industrial applications
- Provides a strong and secure connection
IP65 / IP67 Rated Actuator Type
- Dustproof and water-resistant electric actuator
- Suitable for outdoor or harsh environments
Manual Override Type CPVC Electric Actuator Butterfly Valve
- Equipped with a manual handwheel or override mechanism
- Allows operation during a power failure
Applications of CPVC Electric Actuator Butterfly Valve
Process Industry
High Purity Applications
Electronic Industry
Electrical Industry
Semi-conductors Industry
Pharmaceutical Industry
Solar power panels
Sugar Industry
Paper & Pulp Industry
Nuclear Power Industry
Automotive Industry
DI water plants
Why Choose Petron Thermoplast?
In the field of Oil, gas, water fluid, and chemical injection technology, Petron Thermoplast Company played a leading role, known for innovation and reliability. Petron Thermoplast has engineered a high-performance CPVC Electric Actuator Butterfly Valve that maximises mixing efficiency and durability. Their design is patented to ensure consistent performance across a wide range of flow rates and pressures. Petron Thermoplast CPVC Electric Actuator Butterfly Valve is particularly favoured in chemical treatment applications due to its precision, long service life, and compatibility with corrosive water.
Suitable for Industrial & Utility Applications
Our CPVC Electric Actuator Butterfly Valve is widely used in Oil, gas treatment plants, effluent systems, cooling water lines, chemical handling (mild chemicals), and industrial utilities.
Export-Grade Quality & Standards Compliance
All CPVC Electric Actuator Butterfly Valves are manufactured under strict quality control and comply with international standards, making them suitable for domestic and global projects.
Trusted by EPCs, OEMs & Industries
Petron Thermoplast is a preferred supplier for EPC contractors, OEMs, and industrial operators, offering consistent quality, competitive pricing, and dependable supply.
