CPVC Sediment Strainer
As a Safety Filter, CPVC Sediment Strainer exporter and supplier in India. These are meant to capture any solid contaminants that may sometimes be in the line.
CPVC plastic strainer and other devices with small holes, such as pumps or control valves, are protected by filter strainer. The filter screen is easily replaceable and available in a variety of meshes.
The pump and meter are protected by CPVC Sediment Strainer, which remove suspended particles and contaminants. The position of the screen can be easily determined due to its transparent thermoplastic structure. Optional in-line cleaning valve flushes collected particles from hayward basket strainers.
Because of its True Union design, CPVC sediment strainer is easy to install or repair without enlarging the pipeline. CPVC Sediment strainer is a great filtering capacity and minimum pressure drop are two of its key features.
As a result of the transparent CPVC Sediment Strainer body, the condition of the filter screen can be easily assessed. Everything about CPVC Sediment strainer made by thermoplastic.
CPVC Valves Range
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
CPVC Sediment strainer Technical Information
The RV Sediment strainer limits the passage of any solid particles present in the fluid by means of a strainer.
• Connection system for solvent weld, threaded and flanged joints
• Strainer mounted on an easily removed support that facilitates the clean-
ing or replacement
• Valve material compatibility (PVC-U) with water conveyance, drinking
water and other food substances according to current regulations
• Can be maintained with the valve body installe
| Technical specifications | |
|---|---|
| Construction | CPVC Sediment Strainer |
| Size range | DN 15 ÷ 100 |
| Nominal pressure | PN 16 with water at 20 °C |
| Temperature range | 0 °C ÷ 100 °C |
| Coupling standards | Solvent welding: EN ISO 15493, ASTM F 429. Can be coupled to pipes according to EN ISO 15493, ASTM F 441 Thread: UNI ISO 228-1, DIN 2999, ASTM F 437 Flanging system: ISO 7005-1, EN ISO 15493, EN 558-1 , DIN 2501, ANSI B.16.5 cl.150 |
| Reference standards | Construction criteria: EN ISO 1452, EN ISO 15493 Test methods and requirements: ISO 9393 Installation criteria: DVS 2204, DVS 2221, UNI 11242 |
| Valve material | Body: PVC-C Strainer: PP |
| Seal material | EPDM, FKM |
CPVC SEDIMENT STRAINER
PRESSURE VARIATION ACCORDING TO TEMPERATURE
For water and non-hazardous fluids with regard to which the material is classified as CHEMICALLY RESIS-TANT. In other cases, a reduction of the nominal pressure PN is required(25 years with safety factor).
STRAINER DIMENSIONS
| Pitch (mm) | 0,7 | 1,0 | 1,5 | 2,0 | 2,5 |
|---|---|---|---|---|---|
| number of holes per cm2 | 260 | 125 | 67 | 36 | 26 |
| ASTM series equivalent in strainer | 45 | 70 | 40 | 35 | 30 |
| ø equivalent hole μm | 370 | 200 | 420 | 550 | 580 |
| strainer material | STAINLESS STEEL | PVC-U | PVC-U | PVC-U | PVC-U |
TOTAL STRAINER
AREA ATOT (CM2)
| DN | 10 | 15 | 20 | 25 | 32 | 40 | 50 | 65 | 80 | 100 |
|---|---|---|---|---|---|---|---|---|---|---|
| Atot | 16 | 16 | 23,5 | 36 | 53 | 69 | 101 | 197 | 247 | 396 |
RVUIV-RVUIT
RVUIV PVC-U rigid – RVUIT PVC-U transparent
Sediment strainer with female union ends for solvent welding
| d | DN | PN RVUIV | PN RVUIT | A max | B | E | H | L | Z | Fig. | g | RVUIV EPDM code | RVUIT EPDM code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 16 | 10 | 16 | 16 | 125 | 72 | 55 | 135 | 14 | 107 | A | 203 | RVUIV016E | RVUIT016E |
| 20 | 15 | 16 | 16 | 125 | 72 | 55 | 135 | 16 | 103 | A | 211 | RVUIV020E | RVUIT020E |
| 25 | 20 | 16 | 16 | 145 | 84 | 66 | 158 | 19 | 120 | A | 358 | RVUIV025E | RVUIT025E |
| 32 | 25 | 16 | 16 | 165 | 95 | 75 | 176 | 22 | 132 | A | 526 | RVUIV032E | RVUIT032E |
| 40 | 32 | 16 | 10 | 190 | 111 | 87 | 207 | 26 | 155 | A | 733 | RVUIV040E | RVUIT040E |
| 50 | 40 | 16 | 10 | 210 | 120 | 100 | 243 | 31 | 181 | A | 1095 | RVUIV050E | RVUIT050E |
| 63 | 50 | 16 | 10 | 240 | 139 | 120 | 298 | 38 | 222 | A | 1843 | RVUIV063E | RVUIT063E |
RVIV-RVIT
RVIV PVC-U rigid – RVIT PVC-U transparent
Sediment strainer with female ends for solvent welding
| d | DN | PNRVIV | PNRVIT | Amax | B | E | H | K | L | Z | Fig. | g | RVIV EPDM code | RVIT EPDM code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 75 | 65 | 10 | 6 | 300 | 179 | 104 | 243 | 96 | 33 | 155 | B | 2385 | RVIV075E | RVIT075E |
| 90 | 80 | 6 | 4 | 325 | 192 | 116 | 262 | 105 | 37 | 160 | B | 2975 | RVIV090E | RVIT090E |
| 110 | 100 | 6 | 4 | 385 | 231 | 138 | 325 | – | 61 | 203 | C | 4610 | RVIV110E | RVIT110E |
EXPLODED VIEW
- 1 Body (PVC-U – 1)
- 2 Strainer (PVC-U/STAINLESSsteel – 1)*
- 3 Bonnet (PVC-U – 1)
- 4 Strainer support (PVC-U – 1)
- 5 O-Ring (EPDM-FKM – 1)*
- A-B
- 5 C O-Ring (EPDM-FKM – 2)*
- 6 Washer (PVC-U – 1)
- 7 Union nut (PVC-U – 1)
- 8 Retaining ring (PVC-U – 1)
- 9 Socket seal O-Ring (EPDM-FKM- 2)*
- 10 End connector (PVC-U – 2)*
- 11 Union nut (PVC-U – 2)
The material of the component and the quantity supplied are indicated between brackets
