CPVC Solenoid Valve
• 2-Way PVC-U body
• Installation flexibility and ease of maintenance: high-performance solenoid
electric actuator designed to exceed 5 million maintenance-free operating
cycles
• Adjustable circular section coil with IP65 protection class.
• Integrated override with the possibility of being installed in 3 different positions.
• Lever shutter in EPDM or FKM and lever in stainless steel.
• DIN 43650 electrical connector supplied as standard: includes LED indicator light
and rectifier (in the case of an AC coil).
CPVC Valves Range
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
CPVC SOLENOID VALVE
Technical specifications – S1-S3
| Construction | 2-way solenoid valve |
| Size range | S12: DN 4-6-8 S22: DN 8-10-15 |
| Temperature range | 0 °C ÷ 50 °C |
| Coupling standards | Solvent welding: EN ISO 1452 EN ISO 493 ISO 727 DIN 8063 ASTM D2467 BS 4346-1 ISO 727-2. Can be coupled to pipes according to ISO 161/1 DIN 8062 ASTM D1 1785/76 BS 3506 BS 3505 Thread: ISO 228-1 DIN 2999 ASTM D 2467 (NPT) BS 21 BS 10226 ISO 7-1 |
| Valve material | PVC-U |
| Seal material | EPDM FKM |
maintenance: high-performance
solenoid electric actuator with
internal moving parts designed
to exceed 5 million maintenancefree operating cycles Adjustable
circular section coil with IP65
protection class.
supplied as standard: includes LED
indicator light and rectifier (in the
case of an AC coil).(3.)Lever shutter in EPDM or FKM and
lever in stainless steel.
(4.)Suitable for use with aggressive
fluids: no metal component
in contact with the fluid or
the external environment; all
the screws are covered by
PE protection plugs.
(5.)Emergency override.
TYPE S12 2-WAY VALVE
PERFORMANCE
| DN | 4 | 6 | 8 |
| PN | 6 | 4 | 2 |
| Kv(l/min)* | 6.7 | 12.1 | 15.3 |
TYPE S22 2-WAY VALVE
PERFORMANCE
| DN | 8 | 10 | 15 |
| PN | 6 | 4 | 2 |
| Kv(l/min)* | 27.5 | 34.2 | 58.3 |
* Q flow of litres per minute of water at a temperature of 20°C that will generate ∆p= 1 bar pressure drop
at a certain valve position.
The values shown in the table are calculated with the valve completely open.
GENERAL
CHARACTERISTICS
| Functional characteristics | lever shutter |
| S12 and S22 2-way valve control functions | NC |
| Body material | PVC-U |
| Seal material | EPDM or FKM. |
| Maximum environmental temperature | 50° C |
| Maximum working fluid viscosity | 38 cSt |
| Service | 100% ED |
| Close time | ~ 20 ms |
| Open time | ~ 20 ms |
| Alternating current voltages | 24V – 110V* – 230V |
| Frequency | 50-60 Hz |
| Direct current voltages | 24 V |
| Voltage tolerance | ± 10% |
| S12 absorbed power | 10 W |
| S22 absorbed power | 20 W |
| Electrical protection | IP 65 |
| Electrical connection | DIN 43650 connector with LED (1) |
| Coil thermal class | F (155°C) |
| Installation | In any position |
| Coil rotation | over 360° |
*Voltage upon request
(1) Connector with internal electronic circuit specific to coil used
S12AV
2 way solenoid valve with BS female union ends for solvent welding.
Function: Normally closed
| d | DN | A | B | C | H | H1 | L | Z | E | M | g | EPDM Code | FKM Code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1/4” | 4-6-8 | 24 | 100 | 103 | 92 | 46 | 16 | 60 | 42 | 52 | 400 | See code page | See code page |
| 3/8” | 4-6-8 | 24 | 100 | 103 | 98 | 49 | 19 | 60 | 42 | 52 | 400 | See code page | See code page |
S22AV
2 way solenoid valve with ASTM female union ends for solvent welding.
Function: Normally closed
| d | DN | A | B | C | H | H1 | L | Z | E | M | g | EPDM Code | FKM Code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3/8” | 8-10-15 | 34 | 115 | 130 | 109 | 55 | 19 | 71 | 54 | 67 | 1000 | See code page | See code page |
| 1/2” | 8-10-15 | 34 | 115 | 130 | 116 | 58 | 22 | 72 | 54 | 67 | 1000 | See code page | See code page |
S12LV
2 way solenoid valve with BS female union ends for solvent welding.
Function: Normally closed
| d | DN | A | B | C | H | H1 | L | Z | E | M | g | EPDM Code | FKM Code |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3/8” | 4-6-8 | 24 | 100 | 103 | 88 | 44 | 14 | 60 | 42 | 52 | 400 | See code page | See code page |
