Various Ranges of Products in UPVC Pipes and Fittings

PVC-U is the most adaptable of all plastic materials, allowing it to be customized for a variety of applications involving fluids in motion. PVC-U is one of the more cost-effective thermoplastic materials for partitioning problems in the transportation of corrosive chemical fluids, as well as in the distribution and treatment of water, wastewater, and water treatment sectors.

Main strengths UPVC Pipes and Fittings

  • Chemical resistance: Most acids and alkalis, paraffin/aliphatic hydrocarbons, and saline solutions are chemically resistant.
  • Health friendly: PVC-U is fully compliant with current national and international regulations for the transportation of commodities and drinkable water.
  • Thermal stability: PVC-U resins have good thermal stability at temperatures ranging from 20 to 50 degrees Celsius and are commonly used in waste chemical, industrial, and installation applications. The thermodynamic growth constant is low.
  • Immune to combustion: At 399°C, PVC-U flashes for the purpose. The flame will only continue to burn if the gas concentration is double that of the atmosphere (45 percent) or if there is a flame from an external source.
  • Easy to install: Pipe, fittings, and valves are joined together with adhesives/cement made by dissolving PVC-U polymer in a very solvent combination.

Physical Properties

[/vc_column_text][vc_column_text]

PROPERTIES Quantity
Cell Classification 24448
Tensile strength, psi at 73°F 7,500
Modulus of elasticity tensile, psi at 73°F 380,000
Izod impact, ft.lbs./in. at 73°F, notched 2.0
Compressive strength, psi 10,100
Maximum operating temperature under pressure 200ºF (93ºC)
Thermal conductivity, BTU.in./hr.ft2.°F 0.95
Limited oxygen index (%) 60

[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

Technical Specification of Petron UPVC True Union ball valve

[/vc_column_text][vc_column_text]

Size range DN 10 ÷ 150
Valve materials PVC-U, PVC-C, PP-H, PVDF, ABS, PE
Seal materials EPDM, FPM (O-Ring); PTFE (ball seats)
Nominal pressure PN16 (PVC-U, PVC-C, PVDF, ABS); PN10 (PP-H)
Connections Socket, Spigot, Threaded, Flanged
Control options Manual control; electric actuator; pneumatic actuator

[/vc_column_text][vc_column_text]

Main characteristics

  • Multifunction handle
    Dedicate actuation module Power Quick operations.
    Double groove ball-stem connection.
    Available in all types of seal seat and seal design
    Moulded bracketing for anchoring

Valves are employed in both domestic and business settings. UPVC is mostly utilized as a spherical setting to allow or prevent flow. It contains a ball in the center that permits liquid to flow when the handle is turned on. Hi-tech equipment is available with UPVC ball waves. It is extremely long-lasting and dependable. It is available in a customized design.[/vc_column_text][vc_column_text]

Technical Specification of UPVC Strainers

Construction 2-way piston check valve
Size range DN 10 ÷ 100
Valve materials PVC-U PP-H
Seal materials EPDM, FPM
Nominal pressure PN16 (DN10-25), PN10 (DN32-65), PN6 (DN80-100)
Minimum sealing Pressure 0,015 bar (DN10) to 0,035 bar (DN100)
Connections Socket, Threaded, Flanged

[/vc_column_text][vc_column_text]

Main characteristics

  • Vertical or horizontal installation
  • Piston with counterweight (able to work with high-intensity fluid)
  • No metal part in contact with the fluid
  • Minimum back pressure required
  • Y body for easy maintenance

Applications for Ponmeni plastic piping The inside walls of UPVC Pipes and Fittings are smooth, making them a cost-effective choice. It has an excellent pressure-bearing capacity as well. Strainers provide an unrivaled solution for protecting instruments such as valves, flowmeters, pumps, and other similar devices. Its efficacy is determined by its quality. Strainers are available in a variety of stylish styles. UPVC strainers have high tensile strength and are difficult to break.[/vc_column_text][vc_column_text]

Technical Specifications of UPVC Butterfly Valve

Construction UPVC Butterfly Valve
Size range DN 40 ÷ 400
Disc materials PVC-U, PVC-C (up to DN200), PP-H, PVDF, ABS
Liner material EPDM, FPM, NBR (on request)
Shaft material Stainless Steel AISI 316
Nominal pressure 16 bar (DN40-50), 10 bar (DN65-250), 8 bar (DN300) 7 bar (DN350), 6 bar (DN400)
Connections Flanged wafer, Flanged LUG
Control options Manual control (DN40-200), Gear Box, Pneumatic actuator, Electric actuator

[/vc_column_text][vc_column_text]

Main characteristics

  • UPVC Butterfly Valve Body with ovals holes and inserts (DN40-200)
  • Dry shaft design
  • One body material and 5 discs materials
  • LUG version DIN or ANSI with molded insert
  • Quick actuation by adding flat adapter accordance to ISO5211
  • Ergonomic handle with a device to lock/unlock and quick-adjust in 10 positions

UPVC butterfly valves regulate flow in a system while simultaneously isolating it. When compared to ball valves, it is a more inexpensive option. It is favored over other valves because of its low cost and small weight. This butterfly valve works well even when the pressure and temperature are not excessive.[/vc_column_text][vc_column_text]

Technical Specifications of UPVC Diaphragm Valve

Construction PVC diaphragm valve
Size range DN 15 ÷ 150
Valve materials PVC-U, PVC-C, PP-H, PVDF (ABS)
Diaphragm material EPDM, FPM, NBR, PTFE (with EPDM support)
Nominal pressure PN10, PN 16
Connections Socket, Spigot, Threaded, Flanged
Control options Manual control; pneumatic actuator

[/vc_column_text][vc_column_text]

Main characteristics

  • New body design à Higher flow rate factor
  • Improved linearity in case of flow regulation
  • Ergonomic handwheel and bonnet in PP-GR with PVC cap (excellent chemical resistance)
  • Patented system to adjust and lock the flow in over 300 positions
  • DK Limited version to set the flow
  • Possibility to tag
  • Monolithic flanged body
  • Available in UPVC, CPVC, PPH, PVDF

Petron Thermoplast is a major supplier of UPVC Pipes and Fittings in a variety of sizes and requirements at competitive pricing. Manufacturers and suppliers of PVC and UPVC pipes in India. For the distribution of potable water supply systems, these pipes are the most suitable, simple, and cost-effective options. Petron Thermoplast provides Industrial UPVC pipes and fittings that are made with high-grade plastic and advanced technologies to fulfill quality requirements.

PVC Pipes and Fittings are something we specialize in manufacturing, supplying, exporting, and importing. We are widely used as Adhesives in our PVC Pipes & Fittings and are valued for their precise composition, purity, efficacy, and safe application. For high-pressure water distribution systems, they are employed. PVC solves a number of issues that are common with other plumbing materials. This includes transporting corrosive chemical fluids as well as the distribution and purification of ordinary water.[/vc_column_text][/vc_column][/vc_row]
