PVDF Elbow90 Degree
PVDF Elbow90 Degree Pipe Fitting is made from a specially developed polyvinylidene fluoride compound. These Elbow 90 Degree PVDF Pipes are abrasion resistant, have high mechanical strength, are tough, durable, and can survive harsh weather conditions.
PVDF 90 degree elbow and pipe fittings both durable and modest in weight. Because it is easy to install, it is also cheap. Smooth inner surface ensures frictionless flow and energy savings.
Chemical and corrosion resistance is excellent. It is fire resistant. PVDF Elbow90 degree is also a long lasting, maintenance-free and with an operational life of 50 years. Lead-free water is clean and safe to drink.
PVDF Pipe Fittings Range
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Get Quick Information
90°Elbow S X S
C9Lxx/V9Lxx
| Size | mm | Weight (kg/pc) | ||
|---|---|---|---|---|
| G | H | PVC | CPVC | |
| 1/2” | 15.3 | 37.5 | 0.037 | 0.040 |
| 3/4” | 17.1 | 42.5 | 0.045 | 0.049 |
| 1” | 21.4 | 50.0 | 0.080 | 0.100 |
| 1-1/4” | 26.3 | 58.0 | 0.140 | 0.153 |
| 1-1/2” | 30.1 | 65.0 | 0.185 | 0.202 |
| 2” | 35.9 | 74.0 | 0.270 | 0.295 |
| 2-1/2” | 44.6 | 89.0 | 0.464 | 0.506 |
| 3” | 53.4 | 101.0 | 0.771 | 0.842 |
| 4” | 63.9 | 121.0 | 1.240 | 1.354 |
| 5” | 77.5 | 150.0 | 2.185 | 2.385 |
| 6” | 93.2 | 173.0 | 3.530 | 3.853 |
| 8” | 120.1 | 225.0 | 7.135 | 7.788 |
| 10” | 150.0 | 290.0 | 12.585 | 13.642 |
| 12” | 172.1 | 327.1 | 18.835 | 20.417 |
| 14″ | 197.0 | 426.6 | 26.100 | 28.292 |
| 16″ | 235.4 | 492.0 | 40.890 | 44.020 |
90°Elbow FT X FT
C9LxxT/V9LxxT
| Size | mm | Weight (kg/pc) | ||
|---|---|---|---|---|
| G | H | PVC | CPVC | |
| 1/2” | 15.0 | 33.0 | 0.047 | 0.054 |
| 3/4” | 17.0 | 35.0 | 0.065 | 0.074 |
| 1” | 22.0 | 43.0 | 0.100 | 0.132 |
| 1-1/4” | 26.3 | 52.3 | 0.175 | 0.217 |
| 1-1/2” | 30.0 | 56.0 | 0.234 | 0.314 |
| 2” | 36.0 | 63.0 | 0.428 | 0.471 |
| 2-1/2” | 44.5 | 84.5 | 0.716 | 0.788 |
| 3” | 52.0 | 94.0 | 1.309 | 1.440 |
| 4” | 63.5 | 108.0 | 2.165 | 2.363 |
90°Elbow S X FT
C9LxxA/V9LxxA
| Size | mm | Weight (kg/pc) | |||
|---|---|---|---|---|---|
| G1 | G2 | H | PVC | CPVC | |
| 1/2” | 15.3 | 19.5 | 37.5 | 0.037 | 0.040 |
| 3/4” | 17.1 | 24.5 | 42.5 | 0.045 | 0.049 |
| 1” | 21.4 | 28.0 | 50.0 | 0.080 | 0.087 |
| 1-1/4” | 26.3 | 32.0 | 58.0 | 0.140 | 0.153 |
| 1-1/2” | 30.1 | 39.0 | 65.0 | 0.185 | 0.202 |
| 2” | 35.9 | 47.0 | 74.0 | 0.270 | 0.295 |
| 2-1/2” | 44.6 | 49.0 | 89.0 | 0.464 | 0.506 |
| 3” | 53.4 | 59.0 | 101.0 | 0.771 | 0.842 |
| 4” | 63.9 | 76.6 | 121.0 | 1.240 | 1.354 |
