PPH Flanged Ball Valve
The PPH Flanged Ball Valve is a high-performance, quarter-turn valve designed for reliable shut-off and flow control in demanding industrial applications. Made from Polypropylene Homopolymer (PPH), this valve offers excellent chemical resistance, mechanical durability, and is particularly well-suited for handling corrosive and abrasive fluids.
Featuring flanged ends according to international standards, it allows for secure and easy installation into pipeline systems. Its full-bore design minimizes pressure loss, and the robust construction ensures long-term service in chemical processing, water treatment, and industrial piping systems.
Key Features of PPH Flanged Ball Valve
- Flanged End Connection – Enables secure bolted installation into standard piping systems.
- Full Bore Design – Ensures minimal pressure drop and unrestricted flow.
- Excellent Chemical Resistance – Ideal for corrosive media including acids, alkalis, and solvents.
- Quarter-Turn Operation – Easy and quick manual or actuated control.
- Non-Corrosive Construction – PPH body and components resist rust and degradation.
- Bubble-Tight Shutoff – High-integrity sealing ensures leak-proof performance.
- Maintenance Friendly – Simple design allows easy disassembly and servicing.
Technical Information
| Parameter | Details |
|---|---|
|
Material |
Polypropylene Homopolymer (PPH) |
|
Valve Type |
Flanged Ball Valve (2-way) |
|
Connection Type |
Flanged ends (DIN, ANSI, or ISO standard) |
|
Available Sizes |
DN15 to DN150 (½” to 6”) |
|
Operating Temperature |
0°C to +100°C |
|
Pressure Rating |
Up to 10 bar |
|
Sealing Material Options |
EPDM / FKM (Viton) / PTFE |
|
Operation Type |
Manual handle / Optional actuator (electric or pneumatic) |
|
Body Design |
One-piece or two-piece design depending on size/model |
|
Standards Compliance |
ISO 161, DIN 8077/8078, ISO 15494 |
|
Applications |
Chemical Processing, Acid and Alkali Transfer Lines, Water and Wastewater Treatment, Industrial Effluent Systems, Fertilizer Plants, Mining and Mineral Processing |
PPH Valves
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
