CPVC ELBOW 90
The CPVC Elbow 90° is a type of CPVC pipe fitting used to change the direction of fluid flow by 90 degrees in a piping system. It connects two CPVC pipes at a right angle, allowing the pipeline to turn efficiently without affecting the flow performance. CPVC 90° elbows are commonly used in water supply systems, industrial piping, chemical processing plants, and hot water distribution networks. These fittings are made from Chlorinated Polyvinyl Chloride (CPVC), which provides excellent corrosion resistance, high temperature tolerance, durability, and long service life.
These CPVC elbow 90° pipes and fittings are aabrasion-resistant have high mechanical strength, are tough, durable, and can survive harsh weather conditions. Uses include hot and cold water distribution pipes and industrial liquid handling. CPVC Elbow 90°, in the form of CPVC, is considered safe for the transportation and use of potable water. It is very easy to install. The smooth inner surface ensures frictionless flow and energy savings. Chemical and corrosion resistance are excellent. The CPVC 90° Elbow is fire-resistant and long-lasting maintenance-free.
- Chemical Resistance
- Low Maintenance Requirement
- Low Thermal Conductivity
- Long Service Life
- Easy Installation
- Corrosion Resistance
CPVC ELBOW 90 Details
ID: Inside Diameter
OD: Outside Diameter
WT: Wall Thickness
SL: Socket Length
H: Overall Height
| Size (Inch) | ID (mm) | OD (mm) | WT (mm) | SL (mm) | H (mm) |
| ½” | 21.64 | 29.10 | 3.73 | 22.23 | 42 |
| ¾” | 26.97 | 34.79 | 3.91 | 25.40 | 58 |
| 1″ | 33.78 | 42.88 | 4.55 | 28.58 | 66 |
| 1¼” | 42.55 | 52.25 | 4.85 | 31.75 | 80 |
| 1½” | 48.72 | 58.88 | 5.08 | 34.93 | 90 |
| 2″ | 60.78 | 71.86 | 5.54 | 38.10 | 115 |
| 2½” | 73.56 | 87.58 | 7.01 | 44.45 | 132 |
| 3″ | 89.50 | 113.74 | 7.62 | 47.63 | 150 |
| 4″ | 114.99 | 132.11 | 8.56 | 57.15 | 182 |
| 6″ | 153.88 | 168.10 | 7.11 | 77.25 | 250 |
| Property | Details |
| Product Type | 90° Elbow (Right angle pipe fitting) |
| Function | Changes flow direction by 90° |
| Material | CPVC (Chlorinated Polyvinyl Chloride) |
| Size Range | ½” to 6” (or higher depending on standard) |
| Connection Type | Socket (Solvent Cement) / Threaded (FNPT) |
| Pressure Rating | Up to PN16 / 10–16 bar (depends on SDR & temp) |
| Temperature Range | Up to 93°C continuous service |
| Manufacturing Process | Injection molded |
| Standards | ASTM D2846, ASTM F441, ASTM F439, NSF 14/61 |
| Color | Light grey / off-white |
| Flow Characteristics | Smooth internal surface reduces friction |
| Installation | Solvent welding (leak-proof joint) |
| Applications | Industrial fluids, hot & cold water systems |
| Density / Specific Gravity | ~1.55 g/cm³ |
| Tensile Strength | ~55 MPa |
| Flexural Strength | ~104 MPa |
| Modulus of Elasticity | ~2500–2800 MPa |
| Compressive Strength | ~70 MPa |
| Impact Strength | ~80 J/m (Izod) |
| Hardness | Rockwell ~119 |
| Water Absorption | ~0.03% |
| Heat Deflection Temperature | ~103°C |
| Thermal Conductivity | ~0.14 W/m·K |
| Coefficient of Thermal Expansion | ~6.1 × 10⁻⁵ /°C |
- Right-Angle Direction Change
A CPVC Elbow 90° is designed to change the direction of the pipeline by 90 degrees, allowing smooth flow in industrial piping systems. - High Temperature Resistance
CPVC material can withstand higher temperatures compared to PVC, making the elbow suitable for hot water applications. - Excellent Chemical Resistance
The fitting is resistant to many acids, bases, and salts, making it ideal for chemical and industrial piping systems. - Corrosion and Rust Free
CPVC elbows do not corrode or rust like metal fittings, ensuring long service life and reliable performance. - Smooth Internal Surface
The inner surface of the elbow is smooth, which reduces friction and ensures efficient fluid flow with minimal pressure loss. - Lightweight and Easy Installation
CPVC elbows are lightweight and can be easily installed using solvent cement, reducing installation time and cost. - High Strength and Durability
The material provides good mechanical strength and durability, allowing it to handle pressure and long-term use. - Leak-Proof Jointing
When properly installed with solvent cement, CPVC elbows provide strong and leak-proof connections. - Low Maintenance
Due to its resistance to corrosion, scaling, and chemical damage, CPVC elbows require very little maintenance. - Wide Range of Applications
Used in hot and cold water systems, chemical processing, and industrial fluid handling systems.
| Nominal Size (Inch) | Pressure Rating at 23°C (psi) | Pressure Rating at 23°C (bar) |
| ½” | 400 psi | 27.6 bar |
| ¾” | 400 psi | 27.6 bar |
| 1″ | 315 psi | 21.7 bar |
| 1¼” | 315 psi | 21.7 bar |
| 1½” | 315 psi | 21.7 bar |
| 2″ | 280 psi | 19.3 bar |
| 2½” | 230 psi | 15.9 bar |
| 3″ | 230 psi | 15.9 bar |
| 4″ | 220 psi | 15.2 bar |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Benefits of Using CPVC ELBOW 90
Efficient Direction Change
It allows smooth redirection of fluid flow by 90°, making it ideal for complex piping layouts.
High Temperature Resistance
CPVC elbows can handle higher temperatures compared to standard PVC, making them suitable for hot water systems.
Excellent Corrosion Resistance
The CPVC material resists corrosion, rust, and chemical reactions, ensuring reliable performance in chemical and industrial environments.
Durable and Strong
CPVC elbows provide high mechanical strength and can withstand high pressure and demanding operating conditions.
Smooth Internal Surface
The smooth inner surface minimizes friction and pressure loss, improving flow efficiency.
Lightweight Material
CPVC fittings are lighter than metal fittings, making them easier to transport, handle, and install.
Leak-Proof Connections
When joined with solvent cement or threaded connections, the elbow forms strong and leak-resistant joints.
Low Maintenance
CPVC fittings require minimal maintenance because they do not rust, scale, or corrode over time.
Long Service Life
Due to its chemical and thermal stability, CPVC elbows provide long-lasting performance in piping systems.
Types of CPVC ELBOW 90
Socket (Slip) 90° Elbow
This type has socket ends that allow pipes to be connected using solvent cement welding, creating a strong and leak-proof joint.
Threaded 90° Elbow
Designed with internal or external threads so that pipes can be connected through threaded joints, allowing easy installation and removal.
Street 90° Elbow
One end has a male spigot (plain end), and the other end has a female socket, allowing direct connection to another fitting without an additional pipe piece.
Long Radius 90° Elbow
This type has a larger radius curve that reduces friction and pressure loss, making it suitable for systems requiring smoother fluid flow.
Short Radius 90° Elbow
Designed with a smaller radius curve, commonly used in compact piping systems where space is limited.
Schedule 40 CPVC 90° Elbow.
Used in low to medium pressure applications such as water supply systems.
Schedule 80 CPVC 90° Elbow.
Manufactured with thicker walls to handle higher pressure and industrial piping applications.
Applications of CPVC ELBOW 90
Process Industry
High Purity Applications
Electronic Industry
Electrical Industry
Semi-conductors Industry
Pharmaceutical Industry
Solar power panels
Sugar Industry
Paper & Pulp Industry
Nuclear Power Industry
Automotive Industry
DI water plants
