CPVC Male Adapter
A CPVC Male Adapter is a CPVC pipe fitting used to connect a CPVC pipe to a threaded pipe, valve, or fitting. One end of the adapter has a socket end that is joined to the CPVC pipe using solvent cement, while the other end has external (male) threads for connection to threaded components. The CPVC Male Adapter fitting helps provide a secure and leak-resistant transition between CPVC piping and threaded connections, and it is commonly used in water supply, irrigation, and industrial piping systems. The CPVC male adapter has exposed conductors that can be placed into female connectors to make physical connections. A male connector, often referred to as a plug, is a device used to connect two devices electrically or electronically.
The CPVC Male Adapter connects to a female threaded pipe on the other end of the copper pipe. Adapters can be used to connect two pipes of the same diameter. CPVC Male adapters with two different diameters at both ends can be purchased if a size difference is required between the pipes. Adapter fittings are a type of connection that can be used to extend or terminate a piping system. A CPVC Male Adapter with one or more holes can be inserted into a CPVC connector with one or more holes. When a male connector is unplugged, the exposed conductor can be used to identify it. CPVC connectors provide a reliable electrical and physical connection.
- Chemical Resistance
- Low Maintenance Requirement
- Low Thermal Conductivity
- Long Service Life
- Easy Installation
- Corrosion Resistance
CPVC Male Adapter Details
ID – Inner Diameter
OD – Outer Diameter
WT – Wall Thickness
SL – Socket Length
L – Overall Length (including threaded portion)
| Size (Inch) | ID (mm) | OD (mm) | WT (mm) | SL (mm) | L (mm) |
| ½ | 21.64 | 29.10 | 3.73 | 22.23 | 42 |
| ¾ | 26.97 | 34.79 | 3.91 | 25.40 | 48 |
| 1 | 33.78 | 42.88 | 4.55 | 28.58 | 56 |
| 1¼ | 42.55 | 52.25 | 4.85 | 31.75 | 58 |
| 1½ | 48.72 | 58.88 | 5.08 | 34.93 | 66 |
| 2 | 60.78 | 71.86 | 5.54 | 38.10 | 69 |
| 2½ | 73.56 | 87.58 | 7.01 | 44.45 | 72 |
| 3 | 89.50 | 113.74 | 7.62 | 47.63 | 76 |
| 4 | 114.99 | 132.11 | 8.56 | 57.15 | 81 |
| Property | Details |
| Product Type | Male Adapter (Socket × Male Thread) |
| Function | Connects CPVC pipe to threaded fittings (female thread) |
| Material | CPVC (Chlorinated Polyvinyl Chloride) |
| Connection Type | Socket (Solvent Weld) × Male Thread (MNPT/BSPT) |
| Size Range | ½” to 4” (or higher depending on standard) |
| Thread Type | Male threaded (plastic or brass insert optional) |
| Pressure Rating | Up to 10–16 bar (depends on size & temperature) |
| Temperature Range | Up to 93°C (210°F approx.) |
| Schedule | SCH 40 / SCH 80 / SDR 11 |
| Manufacturing Process | Injection molded |
| Standards | ASTM D2846, ASTM F439, ASTM F437, IS 15778 |
| Certification | NSF 14 / NSF 61 (potable water safe) |
| Color | Grey / off-white |
| Installation | Solvent cement + threaded connection |
| Applications | Industrial piping, water supply systems |
| Density | ~1.50 – 1.60 g/cm³ |
| Tensile Strength | ~50 – 60 MPa |
| Flexural Strength | ~90 – 110 MPa |
| Modulus of Elasticity | ~2400 – 3000 MPa |
| Impact Strength | Moderate to high |
| Hardness | ~80–85 Shore D |
| Water Absorption | ≤ 0.04% |
| Heat Deflection Temp | ~90–105°C |
| Thermal Conductivity | Low (good insulation) |
| Weight | Lightweight (e.g., ~0.046–0.57 lb depending on size) |
- High Temperature Resistance
CPVC male adapters can withstand high temperatures, making them suitable for both hot and cold fluid systems. - Excellent Chemical Resistance
They are resistant to many chemicals, acids, and alkalis, making them ideal for industrial and chemical piping applications. - Corrosion and Rust Free
CPVC material does not corrode or rust like metal fittings, ensuring a longer service life. - Strong Threaded Connection
The male threaded end provides a secure and tight connection with female threaded fittings, valves, or metal pipes. - Lightweight Construction
CPVC male adapters are lightweight, making handling, transportation, and installation easier. - Smooth Internal Surface
The smooth interior reduces friction loss and helps maintain efficient fluid flow. - High Mechanical Strength
They have good impact strength and durability, making them reliable for long-term use. - Easy Installation
These adapters can be easily installed using solvent cement for the socket end and threading for the male end. - Low Maintenance
Due to their corrosion resistance and durability, CPVC male adapters require minimal maintenance. - Long Service Life
The strong CPVC material ensures long-lasting performance in industrial piping systems.
| Pipe Size | Pressure Rating at 23°C (73°F) | Pressure Rating at 60°C (140°F) |
| ½ inch | 400–450 PSI | 180–200 PSI |
| ¾ inch | 370–400 PSI | 170–190 PSI |
| 1 inch | 350–370 PSI | 160–180 PSI |
| 1½ inch | 320–340 PSI | 150–170 PSI |
| 2 inch | 300–320 PSI | 140–160 PSI |
| 3 inch | 260–280 PSI | 120–140 PSI |
| 4 inch | 230–250 PSI | 100–120 PSI |
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
Benefits of Using CPVC Male Adapter
High Corrosion Resistance
CPVC male adapters resist corrosion from chemicals, acids, and alkalis, making them suitable for chemical and industrial piping systems.
Excellent Temperature Resistance
They can handle higher temperatures compared to standard PVC, making them ideal for both hot and cold fluid applications.
Strong and Durable
CPVC male adapters have high mechanical strength and provide long-lasting performance in demanding environments.
Leak-Proof Connections
The threaded male end allows secure and tight connections with other threaded fittings or metal components, reducing the risk of leakage.
Lightweight and Easy Installation
CPVC fittings are lightweight, which makes them easy to transport, handle, and install.
Low Maintenance
Due to their corrosion resistance and durability, CPVC male adapters require very little maintenance.
Smooth Flow Characteristics
The smooth internal surface helps reduce friction loss and ensures efficient fluid flow.
Cost-Effective
Compared to metal fittings, CPVC male adapters are more economical while still offering excellent performance.
Types of CPVC Male Adapter
Plain End CPVC Male Adapter
This type has a plain (socket) end on one side and male threads on the other side. It is used to connect CPVC pipes to threaded fittings or metal components.
Threaded CPVC Male Adapter
It has external male threads designed to connect directly with female threaded fittings or valves in piping systems.
Heavy Duty CPVC Male Adapter
These adapters are designed for high-pressure industrial applications and offer stronger and more durable connections.
Industrial CPVC Male Adapter
Used in chemical processing plants, water treatment facilities, and industrial pipelines where high chemical resistance is required.
Reducing CPVC Male Adapter
This type connects pipes of different diameters while providing a male threaded connection on one end.
Brass Thread Insert CPVC Male Adapter
It contains a brass threaded insert for improved strength and durability when connecting with metal threaded components.
Applications of CPVC Male Adapter
Process Industry
High Purity Applications
Electronic Industry
Electrical Industry
Semi-conductors Industry
Pharmaceutical Industry
Solar power panels
Sugar Industry
Paper & Pulp Industry
Nuclear Power Industry
Automotive Industry
DI water plants
Why Choose Petron Thermoplast?
Petron Thermoplast had a high-quality CPVC Male Adapter that depended on precise manufacturing, quality materials, and adherence to standards. Working with a trusted manufacturer like Petron Thermoplast ensures CPVC Male Adapters that deliver consistent performance in demanding environments. With experience in producing standard and custom designs, Petron Thermoplast provides solutions tailored to the needs of diverse industries worldwide.
