PVDF Y Strainer
The PVDF Y Strainer is a high-performance, corrosion-resistant filtering component used in industrial piping systems to remove debris, particles, and contaminants from process fluids. Constructed from Polyvinylidene Fluoride (PVDF), this Y-type strainer is designed to handle aggressive chemicals and high-purity applications where metallic components are not suitable. Its robust body and precision-molded screen chamber provide consistent filtration with minimal pressure drop, protecting downstream equipment such as pumps, valves, and flow meters.
Ideal for ultra-pure water systems, chemical processing, and wastewater treatment plants, the PVDF Y Strainer ensures smooth operation and prolongs system lifespan by preventing particulate contamination.
Key Features of PVDF Y Strainer
High Chemical Resistance: Suitable for use with aggressive acids, bases, and solvents.
Thermal Stability: Withstands temperatures up to 120°C, ideal for demanding applications.
Transparent/Inspection Port Option: Allows easy visual inspection without dismantling (optional feature).
Removable Filter Screen: Stainless steel or PVDF mesh insert for easy cleaning and maintenance.
Lightweight & Non-Corrosive: Easier to install and handle than metal alternatives.
Low Pressure Drop: Designed for efficient flow with minimal resistance.
Versatile Installation: Can be mounted in horizontal or vertical positions with proper flow direction.
Technical Information
| Parameter | Details |
|---|---|
|
Body Material |
PVDF (Polyvinylidene Fluoride), Injection Molded |
|
Screen Material |
PVDF or 316 Stainless Steel |
|
Available Mesh Sizes |
50, 100, 150, 200 microns (custom options available) |
|
Working Pressure |
Up to 10 bar (145 psi) at 20°C |
|
Temperature Range |
-20°C to +120°C |
|
End Connection Types |
Socket Weld, Threaded (BSP/NPT), or Flanged Ends |
|
Size Range |
DN15 (½”) to DN100 (4”) |
|
Installation Orientation |
Horizontal or Vertical (with flow direction considered) |
|
Standards & Compliance |
ASTM D3222, ISO/DIN Industrial Standards |
|
Typical Applications |
Chemical Processing, Ultrapure Water Systems, Pharmaceutical, Semiconductor Manufacturing, Wastewater Treatment |
PVDF Valves
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
