PVDF 3 Way Ball Valve T-Port Type

A PVDF 3 Way Ball Valve T-Port Type is a chemically resistant plastic valve made from Polyvinylidene Fluoride (PVDF) that allows fluid to flow between three connected pipeline ports. The “T port” refers to the internal bore of the ball, which is shaped like the letter T, enabling multiple flow path configurations. The PVDF 3 Way Ball Valve T-Port Type is a high-performance multi-directional flow control valve designed for use in corrosive and high-purity fluid systems. This PVDF 3 Way Ball Valve T-Port Type offers excellent chemical resistance and thermal stability.

The T-port design allows for various flow configurations, such as mixing or diverting, making it ideal for complex fluid handling in chemical processing, oil, gas treatment, and pharmaceutical applications. The T-port design allows mixing the two inlet flows into one outlet and diverting one inlet flow to two outlets for shut-off or selective directional control. By rotating the ball (usually 90° or 180°), the valve changes the flow path. A PVDF 3 Way Ball Valve T-Port Type is a corrosion-resistant thermoplastic valve with three ports and a T-shaped internal ball that allows mixing, diverting, or directing fluid flow within a piping system.

PVDF 3 Way Ball Valve T-Port Type Details

SIZE (DN) – Diameter Nominal
D – External Diameter
d – Internal Diameter (Bore)
b – Body Width / Flange Thickness
B1 – Internal Depth / Secondary Width
H – Total Height
H1 – Centerline Height
L – Face-to-Face Length
G (ISO Pattern) – Flange Type Designation
ØC – Stem Diameter / Square Size
ØE – Bolt Hole Diameter

Dimensional Data Specifications

SIZE (DN)	D	d	b	B1	H	H1	L
15	54	14	53	30	137	81	22
20	69	22	65	38.5	172	109	24.5
25	82	25	68	46	200	130	28
32	82	25	68	46	208	130	32
40	117	38	92	65	240	154	35
50	117	38	92	65	246	154	38

ISO Mounting Pattern and Stem Details

SIZE (DN)	G (ISO Pattern)	ØC (Stem/Square)	ØE (Bolt Hole Dia)
15	F03	11	5.5
20	F03	11	5.5
25	F03	11	5.5
32	F03	11	5.5
40	F03	14	8.5
50	F03	14	8.5

Parameter	Details
Product Type	3-Way Ball Valve (T-Port Type)
Material (Body)	Polyvinylidene Fluoride (PVDF)
Ball Material	PVDF (solid/machined ball)
Seat Material	PTFE (Teflon)
Seal Material	EPDM / FKM (Viton)
Valve Design	Multi-port (3-way), full bore
Port Type	T-Port (allows mixing/diverting flow paths)
Function	Mixing, distributing, or diverting fluid flow
Working Principle	Quarter-turn (90° rotation) ball controls multiple flow directions
Connection Type	Flanged / Threaded (BSP, NPT) / Socket weld
Size Range	DN15 to DN100 (½″ to 4″)
Pressure Rating	Up to PN10 (~10 bar / 150 PSI)
Operating Temperature	-20°C to +120°C (up to ~150°C max)
Flow Configuration	Allows flow between any two or all three ports
Flow Direction	Multi-directional
Operation Type	Manual lever / Pneumatic actuator / Electric actuator
Actuator Mounting	ISO standard mounting pad
Torque Requirement	Low operating torque
Leakage Class	Bubble-tight sealing
Pressure Drop	Low (full bore design)
Installation Position	Can be installed in any orientation
Density (PVDF)	~1.75 – 1.78 g/cm³
Tensile Strength	~35 – 50 MPa
Chemical Resistance	Excellent (acids, alkalis, solvents)
Thermal Stability	High temperature resistance
UV Resistance	Excellent for outdoor use
Surface Finish	Smooth internal bore (low friction loss)
Construction	Non-metallic, corrosion-resistant body
Maintenance	Low maintenance, replaceable seats/seals
Standards Compliance	DIN / ANSI / JIS (depending on design)
Applications	Chemical processing, water treatment, pharma, semiconductor industries

T-Port Flow Design: Enables three-way flow patterns—ideal for diverting, distributing, or mixing operations.
Excellent Chemical Resistance: PVDF construction resists acids, alkalis, and solvents in harsh environments.
Corrosion-Free Performance: 100% non-metallic construction ensures long service life in corrosive conditions.
Bubble-Tight Shut-Off: Precision-engineered ball and seat ensure leak-proof operation.
Low Torque Operation: Smooth ball movement for manual or automated operation.
Compact & Lightweight: Easy to install in tight piping configurations.
Versatile Connection Options: Available in flanged, socket, or threaded ends.
Manual or Actuated Options: Can be fitted with electric or pneumatic actuators for automation.

Standard Pressure Rating (at 20–25°C)

Valve Size (DN)	Inch Size	Typical Pressure Rating (PN)	Approx. Pressure (Bar)	Approx. Pressure (PSI)
DN15	½”	PN16	16 bar	232 psi
DN20	¾”	PN16	16 bar	232 psi
DN25	1″	PN16	16 bar	232 psi
DN32	1¼”	PN10–PN16	10–16 bar	145–232 psi
DN40	1½”	PN10	10 bar	145 psi
DN50	2″	PN10	10 bar	145 psi
DN65–DN100	2½”–4″	PN6–PN10	6–10 bar	87–145 psi

Temperature vs Pressure Derating

Temperature (°C)	Max Working Pressure (Bar)
20°C	16 bar
40°C	12–14 bar
60°C	8–10 bar
80°C	6–8 bar
100°C	4–6 bar
120°C	2–4 bar

If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.

Benefits of Using PVDF 3 Way Ball Valve T-Port Type

1. Excellent Chemical Resistance

Highly resistant to acids, alkalis, and organic solvents
Ideal for aggressive chemical media
Long service life in corrosive environments

2. Multi-Flow Functionality (T-Port Design)

Allows mixing of two inlet streams
Enables diverting flow to two outlets
Can provide straight-through flow
Reduces the need for multiple valves in piping systems

3. High Temperature Capability

Suitable for elevated temperatures (typically up to ~120–140°C depending on design)
Maintains mechanical strength at higher temperatures compared to many other plastics
