PVDF Pneumatic Actuator 3 Way Ball Valve
• Joint system for solvent-welding (PVC-U and PVC-C only), for welding (PP-H & PVDF), for threading
• Patented SEAT STOP® ball seat carrier system that lets you micro-adjust ball seats and minimize axial force effects.
• Easy radial disassembly allowing quick replacement of O-rings and ball seats without any need for tools
• Radial dismounting valve body (True Union) made for PVC-U, PVC-C, and PP-H injection molding equipped with built-in bores for actuation. ISO 9393 compliant test requisites
• Option of disassembling downstream pipes with the valve in the closed position
• High surface finish stem with double O-Ring and double connection key to the ball, equipped with visual ball position indicator for correct handle installation
• Integrated bracket for valve anchoring
• Possibility of installing pneumatic and/or electric actuators thanks to the robust anchor tower for easy and quick automation using the Power Quick module.
PVDF Valves
Custom Product Manufacturing Available
If you are searching for customized product designs that meet your requirements, don’t worry. Petron Thermoplast also offers custom product manufacturing services to meet the unique needs of various industries. Work with our expert engineers to create custom designs suited for your application.
PVDF Pneumatic Actuator 3 Way Ball Valve
Technical specifications- TKD | |
|---|---|
| Construction | 3-way radial dismounting ball valve with locked carrier and union nuts. |
| Size range | DN 10 ÷ 50 |
| Nominal pressure | PVC-U: PN 16 with water at 20° C PVC-C: PN16 with water at 20° C PP-H: PN10 with water at 20 °C |
| Temperature range | PVC-U: 0 °C ÷ 60 °C PVC-C: 0° C ÷ 100° C PP-H: 0° C ÷ 100° C |
| PVC-U coupling standards | Solvent welding: EN ISO 1452, EN ISO 15493, BS 4346-1, DIN 8063, NF T54-028, ASTM D 2467, JIS K 6743. Can be coupled to pipes according to EN ISO 1452, EN ISO 15493, DIN 8062, NF T54-016, ASTM D 1785, JIS K 6741. Thread: ISO 228-1, DIN 2999, ASTM D 2464, JIS B 0203 |
| PVC-C coupling standards | Solvent welding: EN ISO 15493, ASTM F 439. Can be coupled to pipes according to EN ISO 15493, ASTM F 441 Thread: ISO 228-1, DIN 2999, ASTM F 437 |
| PP-H coupling standards | Welding: EN ISO 15494 Can be coupled to pipes according to EN ISO 15494 Thread: ISO 228-1, DIN 2999 |
| Reference standards | PVC-U construction criteria: EN ISO 16135, EN ISO 1452, EN ISO 15493 PVC-C construction criteria: EN ISO 16135, EN ISO 15493 PP-H construction criteria: EN ISO 16135, EN ISO 15494 Test methods and requirements: ISO 9393PVC-U/PVC-C installation criteria: DVS 2204, DVS 2221, UNI 11242 PP-H installation criteria: DVS 2202-1, DVS 2207-11, DVS 2208-1, UNI 11318Actuator couplings: ISO 5211 |
| Valve material | PVC-U / PVC-C / PP-H |
| Seal material | EPDM, FKM (standard size O-Rings); PTFE (ball seats) |
| Control options | Electric actuator; pneumatic actuator |
Technical specifications – Pneumatic actuator | |
|---|---|
| Reference standards | Construction criteria: Machinery directive 2006/42/CE R.O.H.S. directive 2011/65/CE EN 15714-3 Coupling for valves: ISO 5211, DIN 3337 Compressed air connections: NAMUR VDI\VDE-3845 Top connections for accessories: NAMUR VDI\VDE-3845 |
| Actuator materia | Body: hard coat anodised extruded aluminium. IP67 Bonnet: polyester powder painted aluminium alloy Pinion: nickel-plated carbon steel Other materials available upon request |
| Control air pressure | From 5 to 8 bar. Pmax=10 bar Reduced control pressure executions available upon request |
| Power supply | Dry or lubricated filtered compressed air. If using other fluids, contact the FIP service centre |
| Temperature range | From -20 °C to +80 °C |
| Standard equipment | • Optical position indicator |
| Accessories | • LSQT electromechanical and PNP inductive limit switch boxes (Namur upon request) • Electric-pneumatic positioner 4-20 mA • 3-5/2 way pilot solenoid valves |
| Available options | Body and bonnet with PTFE, AISI 316 or AISI 316 coating with mirror polishing. 304 or 316 stainless steel pinion. |
Technical Data
PRESSURE VARIATION
ACCORDING TO
TEMPERATURE
PVC-U BODY
For water and non-hazardous fluids with regard to which the material is
classified as CHEMICALLY RESISTANT.
In other cases, a reduction of the nominal pressure PN is required (25 years with safety factor).
PVC-C BODY
PP-H BODY
PNEUMATIC ACTUATOR DATA
FUNCTIONAL
CHARACTERISTICS
| Function type | double-acting | Single-acting (SA) |
| Valve opening | air | air |
| Valve closing | air | spring |
ACTUATOR CAPACITY
L: litre, equivalent to 10-3 m3
Air consumption in normal litres (or
normal cubic metres) per operating
cycle can be calculated by correcting
according to operating conditions such
as control air pressure.
| DN | 10 – 15 | 20 ÷ 40 | 50 |
| DA | 0.23 L | 0.45 L | 0.61 L |
| SA | 0.092 L | 0.18 L | 0.244 L |
COMPRESSED AIR
CONNECTIONS
| Function type | Double-acting (DA) | Single-acting (SA) |
| Valve opening | Inlet A | Inlet A |
| Valve closing | Inlet B | – |
TKDIV/CP DA
3 way DUAL BLOCK® ball valve with female metric ends with pneumatic actuator, DoubleActing function “T” ball, configuration 1
| d | DN | PN | E | H | H1 | L | Z | Ra | E1 | g | EPDMCode |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 16 | 10 | 16 | 54 | 118 | 80 | 14 | 90 | G1/8″ | 138 | 1413 | TKDIVDA016E1 |
| 20 | 15 | 16 | 54 | 118 | 80 | 16 | 86 | G1/8″ | 138 | 1943 | TKDIVDA020E1 |
| 25 | 20 | 16 | 65 | 145 | 100 | 19 | 107 | G1/4″ | 155.5 | 2186 | TKDIVDA025E1 |
| 32 | 25 | 16 | 73 | 160 | 110 | 22 | 116 | G1/4″ | 155.5 | 2409 | TKDIVDA032E1 |
| 40 | 32 | 16 | 86 | 188.5 | 131 | 26 | 136.5 | G1/4″ | 155.5 | 2913 | TKDIVDA040E1 |
| 50 | 40 | 16 | 98 | 219 | 148 | 31 | 157 | G1/4″ | 155.5 | 3260 | TKDIVDA050E1 |
| 63 | 50 | 16 | 122 | 266.5 | 179 | 38 | 190.5 | G1/4″ | 155.5 | 5684 | TKDIVDA063E1 |
EXPLODED VIEW
2 Electric actuator (PA6-Nylon – 1)
3 Stem seal (EPDM-FKM – 2)*
4 Stem (PVC-U / PVC-C / PP-H – 1)
5 Ball seal (PTFE – 4)*
6 Ball (PVC-U / PVC-C / PP-H – 1)
7 Body (PVC-U / PVC-C / PP-H – 1)
8 Ball seal O-Rings (EPDM-FKM – 4)*
9 Radial seal O-Ring (EPDM, FKM – 3)
11 Ball seat carrier (PVC-U / PVC-C / PP-H – 3)
12 End connector (PVC-U / PVC-C / PP-H – 3)*
13 Union nut (PVC-U / PVC-C / PP-H – 3)
14 Handle insert (PVC-U – 1)
15 Threaded ring (PVC-U / PVC-C / PP-H – 3)
17 Upper plate (PP-GR – 1)
19 Connection module (PP-GR – 1)
20 Nut (stainless steel – 2)
21 Screw (STAINLESS steel – 4)
22 Screw (STAINLESS steel – 2)
23 Lower plate (PP-GR – 1)
25 Position indicator (POM – 1)
26 DUAL BLOCK® (POM – 3)
